Product Highlights
ü CO sensor
ü High sensitivity, high resolution, detection range 0~1000ppm
ü Low power consumption, working voltage 3V, current <5mA
ü Using the environment: - 20 ℃ to 50 ℃; 15% ~ 90% RH
ü Output UART or analog voltage
ü Cross-threshold report, plus periodic report every 2 hours (the threshold and the periodic report cycle are both user-configurable)
ü OTA (Over The Air) firmware upgrade, including to upgrade loader and application images
ü Analog and digital interface for external sensor connectivity and pulse counting (MPI)
ü Low power consumption, 5 – 10 years of battery operational life with 2 x AA Li-SOCI2 Battery
ü Optional DC 5V power source
ü Integrated internal antenna, or optional external SMA/IPEX antenna
ü Up to 5km reach in NLoS (Non-Line-of-Sight) and up to 18km LoS (Line-of-Sight) environments
ü IP67 enclosure rating
Specifications
Wireless
ISM Band
EU 863 – 870MHz；US 902 – 928MHz
China 779 – 787MHz；EU 433MHz
AS 923MHz；CN 470 – 510MHz
Maximum Link Budget
168dB
Distance
Up to 5km NLOS; up to 18km LOS
Antenna
Integrated internal antenna or external 1/2 wavelength whip antenna (SMA)
Mechanical
Dimension
60mm x 100mm x 30mm (WxS8800)
IP rating
IP67 (WxS8800)
Operating Temperature
-40C to +85C (WxS8800)；
Cable length
0.5 meters
Total Weight
120 g
Electrical
Supply Voltage
3.0 – 3.8 VDC
Power Type
Replaceable 1 or 2 AA 3.6V Li-SOCI2 Battery; DC 4.5V – 12V optional
Compliance/Certification
.png)
LoRaWAN 1.0.2
FCC(America): 2AO7W-WXS8000,
IC(Canada): 23701-WXS8000
ROHS(European Union): R2BJ180927F0664E
