Teklif İsteyiniz
563,20 TL + KDV
Stok Durumu:
Yok
Not
:
Aynı Gün Kargo
15’e kadar aynı gün kargo
Worldwide
Shipment
Next Day
Shipment
Kampanya
{{CMP.TITLE}}
{{CMP.DESCRIPTION}}
- Ürün Özellikleri
- İade ve Teslimat
- Ödeme Seçenekleri
- Yorumlar (0)
- Beni Ara
- Ek
-
Value Description Support Band Quad Band: GSM850, EGSM900, DCS1800, PCS1900 Module automatically searches for frequencies Band selection can be set by AT command Compliant with GSM Phase 2/2+ GPRS connection characteristic GPRS multi-slot class 12 (default) GPRS multi-slot class 1~12 (configurable) GPRS mobile station class B GPRS data feature GPRS data downstream transmission: up to 85.6kbps GPRS data upstream transmission: up to 85.6kbps Encoding format: CS-1, CS-2, CS-3 and CS-4 Support for PAP (Password Authentication Protocol) protocols commonly used for PPP connections Support is usually used for CHAP (Interrogation Handshake Authentication Protocol) protocol Embedded protocol: TCP/UDP/FTP/PPP/HTTP/NTP/MMS/SMTP/PING, etc. Support for unstructured supplementary data services (USSD) Value Description Antenna IPEX Data interface TTL@3.3V compatible with 5V Baud rate Max of 921600bps, 115200bps as default TX power Class 4 (2W)： GSM850 and EGSM900 Class 1 (1W)： DCS1800 and PCS1900 Current consumption (typical) 48mA@5V (idle) 22mA@12V（idle） 14mA@20V（idle） Operating temperature -30℃- +70℃；extending to -40℃~+85℃ Operating voltage DC：5V~20V；powered by lithium battery：3.8V~4.6V Size 42×40×9.7 mm SIM card holder MICRO SIM card holder 3GPP frequency 1 Timeslot 2 Timeslot 4 Timeslot CS-1 9.05kbps 18.1kbps 36.2kbps CS-2 13.4kbps 26.8kbps 53.6kbps CS-3 15.6kbps 31.2kbps 62.4kbps CS-4 21.4kbps 42.8kbps 85.6kbps
Ürün ÖzellikleriFREKANS:2G Module ( GSM / GPRS )
