682,63 TL + KDV
Stok Durumu:
Var
(24 Adet)
Toptan alın indirim fırsatlarını yakalayın!
Miktar
İndirim
5 - 9
%3
10 - 20
%6
Not
:
Notunuzu buraya giriniz.
Aynı Gün Kargo
12.30’a kadar aynı gün kargo
Worldwide
Shipment
Next Day
Shipment
- Ürün Özellikleri
- İade ve Teslimat
- Ödeme Seçenekleri
- Yorumlar (0)
- Döküman
- Beni Ara
- Ek
-
RF Parameter Value Remark Working frequency 862~893 MHz Default: 868MHz Transmitting power 21~30 dBm Default: 30dBm（About 1W） Receiving sensitivity -147 dBm Air data rate: 0.3kbps Air data rate 0.3k~19.2kbps Default: 2.4kbps Test distance 8000 meter In open and clear air, with maximum power, 5dBi antenna gain, height of 2m, air data rate: 2.4kbps Hardware Parameter Value Remark Size 25 * 40.3 mm Antenna type IPX/Stamp hole Communication interface UART Baud rate: 1200~115200, default: 9600 Package SMD Buffer 512 bytes buffer Automatically sub-packaging with 58 bytes per package Electronic parameter Min. Typ. Max. Unit Condition Power supply 3.3 5 5.2 V Communication level 2.5 3.3 3.6 V Transmitting current 560 600 660 mA 30dBm（1W） Receiving current 20 21 23 mA Sleep current 4 5 6 μA Operating temperature -40 20 85 ℃ Operating humidity 10 60 90 % Storage temperature -40 20 125 ℃
Ürün ÖzellikleriFREKANS:868 MHz
