Teklif İsteyiniz
638,74 TL + KDV
Stok Durumu:
Yok
Not
:
Aynı Gün Kargo
15’e kadar aynı gün kargo
Worldwide
Shipment
Next Day
Shipment
Kampanya
{{CMP.TITLE}}
{{CMP.DESCRIPTION}}
- Ürün Özellikleri
- İade ve Teslimat
- Ödeme Seçenekleri
- Yorumlar (0)
- Beni Ara
- Ek
-
Value Description Frequency B8 Module will search frequency automatically NB-IoT connection characteristic NB data downlink transmission：max 85.6kbps NB data uplink transmission：max 85.6kbps Coding format： CS-1、 CS-2、 CS-3 and CS-4 Support for PAP (PasswordAuthentication Protocol) protocols commonly used for PPP connections Support usually used for CHAP (Interrogation HandshakeAuthentication Protocol) protocol Embedded protocol: TCP/UDP etc Support for unstructured supplementary data services (USSD) Value Description Antenna IPEX Data interface TTL@3.3V compatible with 5V Baud rate Max of 230400bps, 115200bps as default TX power 23dBm±2dB Power saving (typical) In power saving mode, max current consumption：5μA In power saving mode, typical current consumption：3.5μA Working temperature -30℃- +70℃；extending to -40℃~+85℃ Working voltage DC：5V~20V；powered by lithium battery：2.5V~3.6V Size 42×40×9.7 mm SIM card holder MICRO SIM card holder 3GPP frequency 1 Timeslot 2 Timeslot 4 Timeslot CS-1 9.05kbps 18.1kbps 36.2kbps CS-2 13.4kbps 26.8kbps 53.6kbps CS-3 15.6kbps 31.2kbps 62.4kbps CS-4 21.4kbps 42.8kbps 85.6kbps
